SCULLY Two-Wire Optic Retain Sensor

SCULLY Two-Wire Optic Retain Sensor – BioSense®

Verifies an Empty Compartment & Warns Against Product Mixing

Maximum safety with Dynacheck®— Automatic and continuous self-checking circuitry when used with Scully electronic rack and vehicle onboard monitoring systems.
Scully’s field-proven electro-optics latest technology using special seals for particular biofuels – First in the industry to create technology for sustainable and greener fuels!
Detection of approximately 9.5mm – 12.7mm (3/8 – 1/2″) of residual product in the compartment.
The sensor is intrinsically safe for mounting in Zone 0 according to ATEX directive 2014/34/EU.

Tech Specs

Features

Two-Wire Optic Retain Sensor - BioSense® Features

Weld coupling material in Carbon-Steel or Aluminum.
Instant-On™—Instant permissive signal. No warmup time is required.
Meets technical requirements according to international standards and practices/codes.

Ordering Information

Two-Wire Optic Retain Sensor - BioSense® Parts

The ordering information below is for FM and FMC approved units. For International ATEX approved models see Retain Optic (Bottom) Sensor data sheet posted above.

Part #	Description
092000295	Standard length BIO seal retain sensor w/ 6061-T651 aluminum weld coupling
092000293	Standard length BIO seal retain sensor w/ carbon steel weld coupling
092000299	Extra length BIO seal retained sensor w/ 6061-T651 aluminum weld coupling
